KL102-1

1.材质：锌合金锁体、塑料面板，镀锌锁片、镀镍传动条2.表面处理：喷无光黑3.适用门板厚度：1~2mm4.备注：锁片开孔8×8

PDF下载 2D下载 3D下载


1.Material: Zinc alloy lock body, plastic panel, galvanized lock plate, nickel plated transmission strip

2.Surface treatment: spray matte black

3.Applicable door panel thickness: 1-2mm

4.Note: Lock plate opening 8 × 8

型号 Producut no.产品单重(g)Weight

装箱数

Lot

KL102-1
39950
