KL-462

1.主体材质:锌合金锁体、镀锌锁片、压板、喷砂镀亮铬齿条2.表面处理:镀沙铬3.适用板厚:1.2~3mm4.锁片开孔:7x7

PDF下载 2D下载 3D下载


1.Main material: Zinc alloy lock body, galvanized lock plate, pressure plate, sandblasted chrome plated gear rack

2.Surface treatment: sandblasted chrome plated

3.Applicable plate thickness: 1.2-3mm

4.Lock plate opening: 7x7

产品型号及特性 Product Number产品单重(g)Weight

装箱数

Lot

镀沙铬 Gray chrome platingKL462-1-1.234360
喷无光黑 Black powder coatedKL462-1-1.834360
