1.Material: PA-6 lock body, copper shaft, galvanized lock plate, nickel plated transmission strip.
2.Applicable door plate thickness: 1-2mm.
3.Remarks: Lock plate opening 8 × 8
| 锁芯类别insert types | 产品型号及特性 ProductNumber | |||||||||||
| 单点式门锁(带钢栓，不带拉杆)one point lock(with cam,without rod) | 双点式门锁(带拉杆，不带钢栓)two point lock(with rod,without cam) | 三点式门镇(带钢栓，带拉杆)three point lock(with cam and rod) | ||||||||||
黑色沙纹面 Matt black | 喷橡皮漆 soft touch | 产品单重（g） Weight | 装箱数 Lot | 黑色沙纹面 Matt black | 喷橡皮漆 soft touch | 产品单重（g） Weight | 装箱数 Lot | 黑色沙纹面 Matt black | 喷橡皮漆 soft touch | 产品单重（g） Weight | 装箱数 Lot | |
| K0100(A) | KL822-1-1A | KL822-1-1A.6 | 408 | 50 | KL822-1-2A | KL822-1-2A.6 | 438 | 50 | KL822-1-3A | KL822-1-3A.6 | 458 | 50 |
| K0133(B) | KL822-1-1B | KL822-1-1B.6 | 425 | 50 | KL822-1-2B | KL822-1-2B.6 | 497 | 50 | KL822-1-3B | KL822-1-3B.6 | 455 | 50 |
| K7010(C) | KL822-1-1C | KL822-1-1C.6 | 438 | 50 | KL822-1-2C | KL822-1-2C.6 | 468 | 50 | KL822-1-3C | KL822-1-3C.6 | 48 | 50 |
| K7030(D) | KL822-1-1D | KL822-1-1D.6 | 442 | 50 | KL822-1-2D | KL822-1-2D.6 | 472 | 50 | KL822-1-3D | KL822-1-3D.6 | 492 | 50 |
