KL-MS-702

1.材质：锌合金主体、PA手柄、镀锌锁片2.表面处理：孔雀绿、兰美束3.打开方式：右旋90°4.适配门板厚度：≤7MM5.专舌配置：选配（4500/4505/4507)6.钥匙：默认无钥匙，选配

PDF下载 2D下载 3D下载

1. Material: Zinc alloy body, PA handle, galvanized lock plate

2. Surface treatment: Peacock green, Lanmei bundle

3. Opening method: Right rotation 90 °

4. Adapted door panel thickness: ≤ 7MM

5. Specialized tongue configuration: optional (4500/4505/4507)

6. Key: default keyless, optional

产品品名/Product Model	产品单重/Weight	装箱数/PCS
MS702	84	300
