KL-MS505

1.材质：锌合金锁体、镀锌压板、锁片2.表面处理：镀亮铬3.适用门板厚度：1-5MM4.备注：锁片有左右之分

PDF下载 2D下载 3D下载



1. Material: Zinc alloy lock body, galvanized pressure plate, lock plate

2. Surface treatment: Bright chrome plating

3. Applicable door panel thickness: 1-5MM

4. Remarks: The locking plate has left and right differences
