KL613-1-1
KL613-2-1
1.Main material: A3 lock housing, lock housing cover, zinc alloy lock tongue.
2.Surface color: blue and white zinc plated
| 基本尺寸 Dimensions | 产品型号Product Number | 产品单重(g)Weight | 装箱数Lot | |||||||||||||
| L1 | L2 | L3 | L4 | L5 | B1 | B2 | B3 | H1 | δ | ∅1 | ∅2 | ∅3 | □ | |||
| 125 | 100 | 76 | 76.5 | 33 | 27.5 | 27 | 24 | 15.5 | 2.3 | 10 | 6 | 6.3 | 8.2 | KL613-1-1 | 164.5 | 200 |
| 101 | 81 | 64 | 64.5 | 25 | 18.5 | 18 | 18 | 11 | 2 | 9 | 5 | 5.3 | 7.2 | KL613-2-1 | 72 | 500 |
