KL-003

1.主体材质:锌合金动、静铰链，分不锈钢和镀镍钢销子2.表面处理:镀亮铬，喷无光黑，细沙纹黑3.备注:转动约180°

PDF下载 2D下载 3D下载

KL003-1


KL003-2


KL003-2A,KL003-2D


KL003-3



1.Main material: Zinc alloy dynamic and static hinges, divided into stainless steel and nickel plated steel pins.

2.Surface treatment: bright chrome plated, sprayed with matte black, fine sand black.

3.Remarks: Rotate about 180 °

产品型号及特性 Product Number
喷无光黑Black powder coated镀亮铬Bright chrome plating产品单重(g)Weight装箱数Lot
KL003-1.3KL003-1.167300
KL003-2.3KL003-2.144400
KL不锈钢Stainless steelKL003-2S50400
KL003-2A
46400
KL003-2D
46400
KL003-3
51400
