KL-104

1.主体材质: 锌合金动、静铰链，不锈钢销子2.表面处理: 镀沙铬3.备注:转动角度约为120°,阻尼铰链

PDF下载 2D下载 3D下载


1.Main material: zinc alloy dynamic and static hinges, stainless steel pins

2.Surface treatment: sand chrome plating

3.Remarks: The rotation angle is about 120 °, and the damping hinge

型号 Product no.扭矩Torque N,m产品单重(g)Weight装箱数Lot
KL-1042.Nm109200
