KL-201-3

1.材质：碳钢/304不锈钢2.表面处理：镀蓝白锌/磁力抛光3.结构说明：可开启角度90°4.性能参数：最大静载荷5.径向载荷：300N,轴向载荷：700N

1. Material: Carbon steel/304 stainless steel

2. Surface treatment: Blue white zinc plating/magnetic polishing

3. Structural description: Can be opened at an angle of 90 °

4. Performance parameters: Maximum static load

5. Radial load: 300N, axial load: 700N

产品型号 Product Model	材质 Material quality	单重 Weight	装箱数 PCS	箱重 Box Weight	装箱规格 Packing sepecification
CL-203	碳钢/不锈钢（304）	42.05g	450	19.3kg	3523.520
