KL-CL-202-3

1.材质：锌合金动铰链、碳钢静铰链压板、销子、螺钉2.表面处理：孔雀绿、炫黑3.结构说明：可开启角度180°4.性能参数：最大静载荷5径向载荷：560N 轴向载荷：520N

PDF下载 2D下载 3D下载

1. Material: Zinc alloy dynamic hinge, carbon steel static hinge pressure plate, pin, screw

2. Surface treatment: Peacock green, dazzling black

3. Structural description: Can be opened at an angle of 180 °

4. Performance parameters: Maximum static load

5 Radial load: 560N Axial load: 520N

产品型号

Product Model

材质

Material quality

单重

Weight

装箱数

PCS

箱重

Box Weight

装箱规格

Packing sepecification

CL202-3

碳钢/锌合金

104.4g/113.07g

240

25.5kg

26.5*24*21
